产品展示
皮升气动灌注系统
SYS-PV830提供喷射压、维持压和真空压力，能够用于卵细胞注射或极小细胞或物体的吸住注射。国产/进口：进口产地/品牌：WPI型 号：SYS-PV830货 号：SYS-PV830
全国热线400-160-1598
在线咨询
产品概述
该泵只提供喷射压和维持压，没有真空压力。喷射压和维持压的作用与 PV830 相同。
产品特征
● 操作简便
手动控制：轻按前面板启动键开始或停止
脚踏开关：脚踏开关灵活控制开始或停止
外部输入：通过计算机编程控制时间参数或 TTL 信号启动
● 双重模式
外部启动：通过计算机控制启动时间
内部启动：通过仪器内部晶体振荡器控制启动时间
● 计量准确
时间参数：具有100 ms和10 s两个时间档，能够精确调节到0.2 ms
体积准确：无论是pL或μL，通过调节时间参数或压力参数均可以准确注射
● 可重复性
通过固定压力、时间和尖端口径一致可确保注射体积的可重复性
产品参数
SYS-PV820&SYS-PV830的参数
| SYS-PV820 | SYS-PV830 | |
| 压力 | ||
| 压力输入 | 0-150psi | 0-150psi |
| 输出压力 | 0.3-90psi | 0.3-90psi |
| 最低调整压力 | 12 in.water | 12 in.water |
| 调整准确性 | 0.1 %(20-turn dial) | 0.1 %(20-turn dial) |
| 调整重复性 | 0.05psi | 0.05psi |
| 测量准确性 | 3 % at full scale | 3 % at full scale |
| 输入连接器 | 快速连接 | 快速连接 |
| 输出连接器 | 带钩(0.158cm内径管) | 带钩(0.158cm内径管) |
| 控制 | 螺线管 | 螺线管 |
| 维持压和注射压 | 维持压和注射压 | |
| 真空 | ||
| 真空输入 | 无 | 0-30.0 in.Hg |
| 真空输出 | 无 | 0.2-29.9 in.Hg |
| 最低调整真空 | 无 | 3 in.water |
| 调整准确性 | 无 | 0.1%(20-turn dial) |
| 调整重复性 | 无 | 0.03 in.Hg |
| 测量准确性 | 无 | 3% at full scale |
| 输入连接器 | 无 | 快速连接 |
| 输出连接器 | 无 | 带钩(0.158 cm内径管) |
| 控制 | 无 | 手动 |
| 通风 | 无 | 空气 |
| 连接 | ||
| 输入 | 3 m尼龙软管（内径：6.4 mm，1000psi）一个1.3 cm NPT内螺纹接头 | |
| 输出 | 两个皮克喷嘴配件，由MPH6S固定架，60-in的 PVC管(200psi）和一个luer接头。 | |
| 物理特征 | ||
| 电源 | 95-135 V / 220-240 V | 95-135 V / 220-240 V |
| 50/60 Hz | 50/60 Hz | |
| 尺寸 | 43×9×24 cm | 43×13×24 cm |
| 运输重量 | 5 kg | 6.3 kg |
参考文献
[1] Conducted dilatation to ATP and K+ in rat skeletal muscle arterioles [J].
KA Dora et al.,Acta Physiol 2017, 219, 202–218.
[2] Origins of Cell-Type-Specific Olfactory Processing in the Drosophila Mushroom Body Circuit [J].
K Inada et al., Neuron. 2017, 95 : 357–367.
[3] The Role of Kv7/M Potassium Channels in Controlling Ectopic Firing in Nociceptors [J].
O Barkai et al., Front Mol Neurosci. 2017; 10: 181.
[4] A Population of Projection Neurons that Inhibits the Lateral Horn but Excites the Antennal Lobe through Chemical Synapses in Drosophila [J].
K Shimizu et al., Front Neural Circuits. 2017, 11 : 30.
[5] Cell-Specific PKM Isoforms Contribute to the Maintenance of Different Forms of Persistent Long-Term Synaptic Plasticity [J].
J Hu et al., Journal of Neuroscience 2017, 37 (10) : 2746-2763.
[6] KV7/M channels as targets for lipopolysaccharide-induced inflammatory neuronal hyperexcitability [J].
A Tzour et al., J Physiol 2017, 595(3) : 713–738.
[7] Nicotinic activity depresses synaptic potentiation in layer V pyramidal neurons of mouse insular cortex [J].
H Sato et al., Neuroscience 2017, 358 : 13-27.
[8] Gold Nanobeacons for Tracking Gene Silencing in Zebrafish [J].
M Cordeiro et al., Nanomaterials 2017, 7(1) : 10.
[9] Ultrafast optical recording reveals distinct capsaicin-induced ion dynamics along single nociceptive neurite terminals in vitro [J].
RH Goldstein et al., J. Biomed. Opt. 2017, 22(7) : 076010.
[10] NEAP/DUSP26 suppresses receptor tyrosine kinases and regulates neuronal development in zebrafish [J].
CH Yang et al., Scientific Reports 2017, 7 : 5241.
[11] Inward rectifier K+ channel and T-type Ca2+ channel contribute to enhancement of GABAergic transmission induced by β1-
adrenoceptor in the prefrontal cortex [J].
F Luo et al., Experimental Neurology 2017, 288 : 51–61.
[12] A neural circuit architecture for angular integration in Drosophila [J].
J Green et al., Nature 2017, 546 : 101–106.
[13] Selective Erasure of Distinct Forms of Long-Term Synaptic Plasticity Underlying Different Forms of Memory in the Same
Postsynaptic Neuron [J].
J Hu et al., Current Biology 2017, 27 : 1888–1899.
[14] Probing the adhesion properties of alginate hydrogels: a new approach towards the preparation of soft colloidal probes for
direct force measurements [J].
N Helfricht et al., Soft Matter, 2017, 13 : 578—589.
[15] Neurokinin-1 receptor blocker CP-99 994 improved emesis induced by cisplatin via regulating the activity of gastric distention
responsive neurons in the dorsal motor nucleus of vagus and enhancing gastric motility in rats [J].
X Sun et al., Neurogastroenterology & Motility 2017 : e13096.
[16] A high-throughput functional genomics workflow based on CRISPR/Cas9-mediated targeted mutagenesis in zebrafish [J].
GK Varshney et al., Nature Protocols 2016, 11 : 2357–2375.
[17] Development of a vestibular schwannoma xenograft zebrafish model for in vivo antitumor drug screening [J].
H Lee et al., Laryngoscope 2016, 126 : E409–E415.
产品用途
● 斑马鱼研究的应用：
√ 斑马鱼卵细胞的基因物质、药物及染料注射
√ 斑马鱼幼鱼的药物、染料的微量注射
● 啮齿类小动物大鼠及小鼠等卵细胞基因物质、药物及染料注射
● 昆虫研究的应用：
√ 卵细胞注射或体内药物或染料注射
● 爪蟾卵细胞基因物质及染料注射
√ 细胞核或细胞器移植：使用PV830可以用于哺乳动物细胞核或细胞器移植；
√ 嗅觉或味觉感应神经元的PUFF给药：用于果蝇、飞蛾、大鼠、小鼠等动物的嗅觉、味觉或神经递质的PUFF给药；
